High Frequency 100Khz Line Micro Nano Mist Sprayer
Description:
100K high-frequency ultrasonic line spray nozzle is a kind of spray nozzle, which is mainly used in ultrasonic atomization technology. The nozzle with 100K frequency can produce small and uniform droplet atomization, which is suitable for occasions with high requirements for precision and consistency of spray particles, such as cosmetics, perfume, drugs, etc. Fine control of atomization effect can be achieved by adjusting the frequency and power of ultrasonic waves.
The 100K high-frequency ultrasonic line spray type uses a piezoelectric ceramic vibrator to break the liquid and form atomization through ultrasonic vibration. Compared with traditional compressed gas nozzles, ultrasonic line spray nozzles have fine and uniform atomization particles with particle sizes less than 10 microns, which is conducive to uniform coverage and deep penetration.
Parameters:
| Model | FSW-1005-L |
| Name | 100Khz Line Ultrasonic Nozzle Atomization |
| Frequency | 100Khz |
| Atomized particle size range(μm) | 15-40 |
| Spray width(mm) | 0.5-2 |
| Spray flow(ml/min) | 0.01-1 |
| Spray height(mm) | 10-20 |
| Liquid viscosity (cps) | <15 |
| Particle size (μm) | <8 |
| Diversion pressure (Mpa) | <0.02 |
| Application | Suitable for Medical balloon, stent, fine wire spraying |
Application :
Ultrasonic line spray nozzles are not only used in the cosmetics industry, but also have wide application scenarios in the following fields:
1. Pharmaceutical industry:
Drug nebulization administration, such as inhalation administration of respiratory system drugs such as asthma
Disinfection spray, such as hospital environment and hand disinfection
2. Agricultural industry:
Pesticide spray, which can realize uniform and delicate pesticide spraying
Application of plant nutrient solution to promote crop growth
3. Industrial applications:
Industrial cleaning and dust removal, such as equipment cleaning in electronic factories
Lubricant spray, such as lubrication of gears and machine parts
4. Daily necessities industry:
Household disinfection spray
Aromatherapy essential oil spray
5. Automotive industry:
Car air purification and deodorization
Surface protection and beautification of car paint
In general, the ultrasonic linear spray nozzle is widely used in many fields that need accurate atomization, relying on its delicate, uniform, efficient, energy-saving, pollution-free and other characteristics, and is a very practical spray technology. Suitable nozzle parameters and configurations can be selected according to specific needs in different industries and scenarios.
High Frequency 100Khz Line Micro Nano Mist Sprayer
